LensunSolar Flexible Hood Solar Panel (85-Watt) with MPPT Charge Controller & Vinyl Decal for 3rd-Gen 4Runner (1996–2002)

Bundle • Free Shipping
Sale price$454.00 Regular price$699.00
Save $245.00
Corgrit Identification Code: C-LEN-0040

In stock

The LensunSolar Flexible Hood Solar Panel with MPPT Charge Controller and Vinyl Decal is a complete hood-mounted power solution for the 3rd-generation Toyota 4Runner. Rated at 85 watts, it keeps vehicle and auxiliary batteries charged and supports portable power stations while driving or parked. The ETFE-coated panel reduces glare, resists extreme conditions, and installs directly over the included vinyl decal for paint protection. Paired with the 10-A MPPT controller, it delivers efficient, intelligent, and safe charging in all environments.

Key Features

Custom Hood Fit for 3rd-Gen 4Runner
Includes Vinyl Decal for Hood Paint Protection
ETFE Film Surface with Heat, UV, and Corrosion Resistance
10-A Waterproof MPPT Charge Controller

LensunSolar

2-Year Warranty Protection


Corgrit Coverage

Dedicated Assistance and Streamlined, No-Hassle Claims

Explore

Solar Panel Specifications

Engineered for off-grid dependability, the LensunSolar hood solar system combines an 85-Watt flexible panel, protective vinyl decal, and 10A MPPT charge controller for a streamlined energy solution. The decal prevents hood damage during installation, while the controller optimizes charging efficiency across multiple battery chemistries. Together, the system powers fridges, lighting, cameras, and portable stations without draining vehicle batteries.

Fits

3rd-Gen Toyota 4Runner (1996–2002)

Materials

Grade A PERC monocrystalline solar cells
Heat-, corrosion-, and ultraviolet-resistant ETFE film

Weight

4.4 lb

Power Output

Maximum Power (Pmax): 85 W
Voltage at Maximum Power (Vmp): 17 V
Current at Maximum Power (Imp): 5 A

Electrical Specifications

Open-Circuit Voltage (Voc): 20 V
Short-Circuit Current (Isc): 5.5 A
Maximum System Voltage: 500 V
Power Allowance Range: +/-3%

Junction Box

IP68-rated with 5-ft pre-attached cables

Solar Cell Efficiency

23.5%

Test Conditions

Air Mass: AM1.5
Irradiance: 1000 W/m²
Cell Temperature: 77°F/25°C

SKU

LS-85FX2-4R+FULLKIT

Included in the Box

(1) LensunSolar solar panel
(1) Charge controller
(1) Decal

Overview

The LensunSolar 85-Watt Flexible Hood Solar Panel provides 3rd-gen Toyota 4Runner owners with continuous battery maintenance and off-grid energy independence. It supports direct charging of vehicle and auxiliary batteries, powers essential accessories, and integrates seamlessly without occupying cargo space. The ETFE-coated surface minimizes glare, enhances durability, and ensures consistent performance in demanding environments.

Construction

Built from high-grade PERC monocrystalline solar cells, the panel delivers 23.5% efficiency for maximum energy density in a compact format. Laminated beneath an ETFE protective layer, it resists UV exposure, corrosion, and heat degradation. At just 3 mm thick and 2 kg, the lightweight, flexible build conforms to the hood profile while withstanding snow, ice, mud, rocks, and hail.

Design

Shaped precisely to fit the 3rd-gen 4Runner hood, the panel integrates seamlessly with factory lines. Its ultrathin profile maintains vehicle aerodynamics and handling while providing a clean, low-profile aesthetic. Optional accessories include a vinyl decal for paint protection and a waterproof MPPT controller for intelligent energy management.

Performance

Rated for 85-Watt peak output, the panel keeps 4Runner batteries topped up even during extended parked intervals. It ensures reliable power for overlanding setups, camping equipment, and portable stations. The design reduces hood glare while extending battery lifespan by counteracting undercharging and storage-related degradation.

Installation

No drilling or structural modifications are required. Plug-and-play wiring enables straightforward integration, while optional pre-wired MPPT controllers add overcharge and polarity protection. The custom vinyl decal is recommended to safeguard paint and enhance long-term mounting.
